Erica Synths Bassline

42009

2 600,00 DKK

-10%

2 340,00 DKK

Erica Synths

1 på lager

Erica Synths Bassline is fully analogue synth voice module for ultimate basslines and leads. It features AS3340 VCO with three waveforms, a filter inspired by Erica Synths Acidbox and unique features - transistor based suboscillator and two BBD lines that emulate VCO detune creating a sound of massive polysynth from one oscillator. Accent provides more expression to the bassline, by adding volume and opening the VCF slightly.

Features

  • Fully analogue circuit
  • Great 1V/oct tracking
  • Simultaneous Triangle, Square and Master outputs
  • Accent input
  • Transistor-based suboscillator
  • BBD-based VCO detune emulation
  • Integrated VCF and VCA decay envelopes
  • LP/BP VCF
  • External VCO FM and VCF cutoff CV inputs

This module to me is the star. Erica’s stroke of genius here is combining that three-waveform oscillator with a transitor-based sub-oscillator for more bass, plus their ultra-violent Acidbox-style filter, plus a detune that’s actually not a detune but two bucket brigade delays acting like one. What you get from that potent brew is leads and basslines that can go full spectrum from melody to noise, and a filter/detune combination that makes it absolutely punch people in the gut. And it makes perfect sense in a modular, because all that insanity lends itself to patching, from the frequency modulation input to modulating the filter. - CDM



As a partner to the Erica drum modules, the Bassline module is a neat, self-enclosed synth voice with its own character and a few worthwhile extras. If you don't mind the limitations, it could add a fresh acidic layer to any system.- Sound On Sound

Pitch range C0-C8
Audio output level -5...+5V
CV level (full span) -5V-+5V
Power consumption +110mA, -70mA
Module width 14HP
Module depth 35mm

Technical specification:

Power consumption

+12mA, -11mA

Module width

3HP

Module depth

35mm


Erica Pico VCF1 on Modulargrid

Der er ingen kundeanmeldelser endnu.

Skriv din bedømmelse

Erica Synths Bassline

Erica Synths Bassline

Erica Synths Bassline er et fuldt analogt synth-stemmemodul til ultimative basslines og leads

  • Fully analogue circuit
  • Great 1V/oct tracking
  • Simultaneous Triangle, Square and Master outputs
  • Accent input
  • Transistor-based suboscillator
  • BBD-based VCO detune emulation
  • Integrated VCF and VCA decay envelopes
  • LP/BP VCF
  • External VCO FM and VCF cutoff CV inputs

Skriv din bedømmelse

2 600,00 DKK

-10%

2 340,00 DKK

Erica Synths

1 på lager

Erica Synths Bassline er et fuldt analogt synth-stemmemodul til ultimative basslines og leads

  • Fully analogue circuit
  • Great 1V/oct tracking
  • Simultaneous Triangle, Square and Master outputs
  • Accent input
  • Transistor-based suboscillator
  • BBD-based VCO detune emulation
  • Integrated VCF and VCA decay envelopes
  • LP/BP VCF
  • External VCO FM and VCF cutoff CV inputs
  • 14HP
  • 35mm
  • +12V:110mA - 12V:70mA
